Mopa - JPT Laser for Colors Marking
Laser Source: JPT
Laser Type: fiber laser
Output Power (W): Mopa 20=20W, Mopa 30=30W, Mopa 60=60W
Marking Speed (mm/s): 0-10000
Standard Marking Field (mm): 150*150(70*70/110*110/175*175)
Maximum Marking Height (mm): 150
Laser Wavelength (nm): 1064
Beam Quality (m²): Mopa 20/30≤1.3, Mopa 60≤1.5
Repeat Accuracy (mm): Mopa20/30=Spectral width<15mm, Pause energy 0.8mJ; Mopa 60=Spectral width<15nm, Pause energy 1.5mJ
Minimum Character (mm): Mopa 20/30=Pulse width 2-350ns, Line Space: 0.001mm; Moap 60=Pulse width 2-500ns, Line Space: 0.001mm
Frequency (KHz): Frequency Range 1-4000kHz (1-3000), Full Power Frequency Range 25-4000kHz (37-3000)
Operation Temperature (℃): 0-40
Cooling Method: Air Cooling
Lifespan (Hours): 100,000
Net Weight (Kg): 14.5/18
Dimension (L*W*H*T mm): Mopa 20/30=437*307*545*88, Mopa 60=475*325*545*90
Package Size (L*W*H mm): 760*540*170
Supply Voltage (V): DC24V
Power Consumption (W): Mopa 20≤120, Mopa 30≤144, Mopa 60≤300
PC Connection: USB Cable
Certificate: CE, FDA, RoHS, SGS, ISO9001
Color Available: Black+Red
Cutting Function: YES
Rotary Function: Optional
Lens Replacement: Y
Thermal Protection: Y
Emergency Stop: Y
Design: Quick Set-Up + Color Marking + Unlimited Marking Height
Marking Software: EZCAD/LightBurn
Operating System: Windows & MAC & Linux -
Basic - Affordable Laser
Laser Source: MAX
Laser Type: fiber laser
Output Power (W): Basic 1=20W, Basic 2=25W
Marking Speed (mm/s): 0-10000
Standard Marking Field (mm): 110*110 (70*70/150*150/175*175)
Maximum Marking Height (mm): 200
Laser Wavelength (nm): 1064
Beam Quality (m²): Basic 1≤1.4, Basic 2≤1.6
Repeat Accuracy (mm): ±0.002
Minimum Character (mm): 0.01
Minimum Line Distance (mm): 0.01
Frequency (KHz): 20-60
Operation Temperature (℃): 10-42
Cooling Method: Air Cooling
Lifespan (Hours): 100,000
Net Weight (Kg): 11.5
Dimension (L*W*H*T mm): 435*305*525*70
Package Size (L*W*H mm): 760*540*170
Supply Voltage (V): DC24V
Power Consumption (W): Basic 1≤160, Basic 2≤180
PC Connection: USB Cable
Certificate: CE, FDA, RoHS, SGS, ISO9001
Color Available: Black/Orange
Cutting Function: Basic 1=NO, Basic 2=YES
Rotary Function: Optional
Lens Replacement: Y
Thermal Protection: Y
Emergency Stop: Y
Design: Quick Set-Up + Unlimited Marking Height
Marking Software: EZCAD/LightBurn
Operating System: Windows & MAC & Linux -
One/Nova - Foldable Laser
Laser Source: MAX
Laser Type: fiber laser
Output Power (W): ONE=20W, NOVA=25W
Marking Speed (mm/s): 0-10000
Standard Marking Field (mm): 110*110 (70*70/150*150)
Maximum Marking Height (mm): 90
Laser Wavelength (nm): 1064
Beam Quality (m²): ONE≤1.4, NOVA≤1.6
Repeat Accuracy (mm): ±0.002
Minimum Character (mm): 0.01
Minimum Line Distance (mm): 0.01
Frequency (KHz): 20-60
Operation Temperature (℃): 10-42
Cooling Method: Air Cooling
Lifespan (Hours): 100,000
Net Weight (Kg): 8.5
Dimension (L*W*H*T mm): 370*258*505*65
Package Size (L*W*H mm): 760*540*170
Supply Voltage (V): DC24V
Power Consumption (W): ONE≤160, NOVA≤180
PC Connection: USB Cable
Certificate: CE, FDA, RoHS, SGS, ISO9001
Color Available: Black/Grey
Cutting Function: ONE=NO, NOVA=YES
Rotary Function: Optional
Lens Replacement: Y
Thermal Protection: Y
Emergency Stop: Y
Design: Foldable Design
Marking Software: EZCAD/LightBurn
Operating System: Windows & MAC & Linux -
Super - High Power Laser
Laser Source: MAX
Laser Type: fiber laser
Output Power (W): Super 30=30W, Super 50=50W
Marking Speed (mm/s): 0-10000
Standard Marking Field (mm): 110*110(70*70/150*150/175*175)
Maximum Marking Height (mm): 200
Laser Wavelength (nm): 1060-1070
Beam Quality (m²): ≤1.6
Repeat Accuracy (mm): ±0.002
Minimum Character (mm): 0.01
Minimum Line Distance (mm): 0.01
Frequency (KHz): 20-60
Operation Temperature (℃): 10-42
Cooling Method: Air Cooling
Lifespan (Hours): 100,000
Net Weight (Kg): 14
Dimension (L*W*H*T mm): 435*305*545*90
Package Size (L*W*H mm): 760*540*170
Supply Voltage (V): DC24V
Power Consumption (W): Super 30≤140, Super 50≤200
PC Connection: USB Cable
Certificate: CE, FDA, RoHS, SGS, ISO9001
Color Available: Black+Red
Cutting Function: YES
Rotary Function: Optional
Lens Replacement: Y
Thermal Protection: Y
Emergency Stop: Y
Design: Quick Set-Up + High Power + Unlimited Marking Height
Marking Software: EZCAD/LightBurn
Operating System: Windows & MAC & Linux -
PC - Built-in PC Laser
Laser Source: MAX
Laser Type: fiber laser
Output Power (W): PC 1=20W, PC 2=25W
Marking Speed (mm/s): 0-10000
Standard Marking Field (mm): 110*110 (70*70/150*150)
Maximum Marking Height (mm): 90
Laser Wavelength (nm): 1064
Beam Quality (m²): PC 1≤1.4, PC 2≤1.6
Repeat Accuracy (mm): ±0.002
Minimum Character (mm): 0.01
Minimum Line Distance (mm): 0.01
Frequency (KHz): 20-60
Operation Temperature (℃): 10-42
Cooling Method: Air Cooling
Lifespan (Hours): 100,000
Net Weight (Kg): 8.5
Dimension (L*W*H*T mm): 370*258*505*65
Package Size (L*W*H mm): 760*540*170
Supply Voltage (V): DC24V
Power Consumption (W): PC 1≤160, PC 2≤180
PC Connection: Built-in PC
Certificate: CE, FDA, RoHS, SGS, ISO9001
Color Available: Black/Grey
Cutting Function: PC 1=NO, PC 2=YES
Rotary Function: N
Lens Replacement: Y
Thermal Protection: Y
Emergency Stop: Y
Design: Foldable Design + Built-in PC
Marking Software: EZCAD/LightBurn
Operating System: Windows & MAC & Linux -
Pro - Auto Focus Laser
Laser Source: MAX
Laser Type: fiber laser
Output Power (W): Pro 1=20W, Pro 2=25W
Marking Speed (mm/s): 0-10000
Standard Marking Field (mm): 110*110 (70*70/150*150)
Maximum Marking Height (mm): 90
Laser Wavelength (nm): 1064
Beam Quality (m²): Pro 1≤1.4, Pro 2≤1.6
Repeat Accuracy (mm): ±0.002
Minimum Character (mm): 0.01
Minimum Line Distance (mm): 0.01
Frequency (KHz): 20-60
Operation Temperature (℃): 10-42
Cooling Method: Air Cooling
Lifespan (Hours): 100,000
Net Weight (Kg): 8.5
Dimension (L*W*H*T mm): 370*258*505*65
Package Size (L*W*H mm): 760*540*170
Supply Voltage (V): DC24V
Power Consumption (W): Pro 1≤160, Pro 2≤180
PC Connection: USB Cable
Certificate: CE, FDA, RoHS, SGS, ISO9001
Color Available: Black
Cutting Function: Pro 1=NO, Pro 2=YES
Rotary Function: N
Lens Replacement: Y
Thermal Protection: Y
Emergency Stop: Y
Design: Foldable Design + Auto-Focus
Marking Software: EZCAD/LightBurn
Operating System: Windows & MAC & Linux
