How to Get Your EM-Smart Dual Laser Engraver Ready

MullerYvonne |


To ensure good performance and longevity of the machine, it is essential to set up the EM-Smart Dual laser engraver properly. Here are the necessary steps to help you, from understanding its components to getting the machine ready for use.

1. What's Inside the EM-Smart Dual Laser Engraver Package?

Upon inspecting the package after delivery, you will find the following items:

  • 16GB USB flash drive
  • Pipe for ventilation
  • Power adapter for reliable power supply
  • USB cables (Type-C & Type-B) for connectivity
  • Cutting panel to protect materials and the machine’s baseplate
  • Hex wrench for assembly and adjustments
  • L-shaped positioning piece for precise material placement
  • Material pack for testing and initial projects
  • Quick start guide and safety instructions

Familiarizing yourself with these items will ensure a smoother engraving process.

12-items-involved-in-the-product-package

2. Getting to Know the EM-Smart Dual Laser Engraver's Structure

Before operating the machine, it's essential to understand its structure. The EM-Smart Dual laser engraver consists of several key components, including the camera, protective enclosure, smoke outlet, various ports, field lens protector, emergency stop switch, power switch, up/down buttons, and more. Understanding the functions of these parts will help you operate the machine safely and efficiently

The-structure-and-function-of-each-button

3. Step-by-Step Guide to Getting EM-Smart Dual Laser Ready

Step 1: Remove the Protective Cover from the Field Lens

The field lens is a crucial component, and it comes with a protective cover to prevent dust accumulation. Always remove the cover before using the machine. If you plan to store the engraver for an extended period, reinstall the cover to keep the lens clean.

Removing-protective-cover

Step 2: Check the Emergency Stop Switch

Ensure the emergency stop switch is in the released position before turning on the machine. If the switch is pressed down, simply turn the knob to reset it.

It is worth noting that in case of an emergency, you can press the emergency stop switch to shut down the machine immediately. Once the situation is resolved, turn the knob to reset it and resume operation.

Resetting-the-emergency-stop-button

Step 3: Install the Ventilation Pipe

Proper ventilation is essential for safe engraving and cutting. Connect the provided pipe to the exhaust outlet to direct fumes away from the workspace.

Connecting-the-pipe

Step 4: Connect the Power Supply

Plug in the power adapter and ensure a stable connection. Note that this does not mean your machine is powered on yet. First, press the emergency stop button again, then hold the power switch for 3-5 seconds until you hear the fan start. Once you hear the fan start, release the emergency stop button, and your machine will be powered on successfully. After that, your machine is ready for software setup and operation.

Power-on-the-machine

4. Proper Use of Accessories for Optimal Performance

Using the Cutting Panel

When cutting materials, place the cutting panel underneath to prevent scorching on the material’s backside and to protect the baseplate from damage.

Installing-cyutting-panel-for-protecting-baseplate

Using the L-Shaped Positioning Piece

For batch processing or repeated engravings, the L-shaped positioning piece ensures that your materials are aligned consistently, improving accuracy and efficiency.

Installing-L-shaped-positioning-piece-for-bulk-engraving

By following these steps, you can efficiently set up your EM-Smart Dual laser engraver and maximize its performance. Additionally, proper maintenance and correct use of accessories will help you achieve precise, high-quality engraving results.

Now that your machine is ready, it's time to connect it to LightBurn software and begin your engraving journey!
